Electrocompaniet

ECI-80D

https://www.mgmaudio.ch/web/image/product.template/2176/image_1920?unique=3e363e0

Integrated Amplifier

CHF 3'144.31 3144.31 CHF CHF 3'144.31 Inklusive MwSt.

CHF 3'144.31 Inklusive MwSt.

Preis auf Anfrage

Auf Lager

Diese Kombination existiert nicht.

Geschäftsbedingungen
Versand: 2-3 Arbeitstage

The ECI 80D is our brand new integrated amplifier. The new ECI 80D offers 2 x 80 Watts into 8 Ohms, using an in-house developed Class A/B Amplifier.
We have equipped it with a built-in RIAA pre-amplifier for your LP player (MM cartridge support), 2-way Bluetooth HD for both streaming from your iOS, Android unit, Mac, or PC, and also HD streaming to your High-end headphones. And of course a 5-input DAC (3 Toslink, 2 COAX)

Technical specifications


PREAMPLIFIER:

Input impedance: 75 kOhms

Noise floor:< -130dB

THD+N: < 0.002%

Frequency response (-3dB): 1 – 150 kHz

Volume adjustment range: - 110dB to +15 dB



OUTPUT AMPLIFIER:

THD+N: < 0.005%

Output power (into 8 Ohms): 2 x 80W

Output power (into 4 Ohms): 2 x 150W

Damping factor (8 Ohms load): > 300

Frequency response (-3dB): 1 – 150kHz

SNR (input shorted, ref 1W into 8 ohms, A-weighted): 102 dB

Gain: 25 dB

Protection: DC, overload, temperature



RIAA PHONO:

Pickup support: Moving Magnet

Gain: 40 dB @ 1kHz

Input impedance: 47 kOhms || 100pF

RIAA correction accuracy: +/-0.1dB, 25-20kHz

Subsonic filter: -3 dB @ 14 Hz

THD: < 0.001%

SNR: 83 dB (A-weighted)

Overload margin: 30dB @ 1kHz



HEADPHONE AMPLIFIER:

THD+N: < 0.001%

Load impedance single output in use: > 16 Ohms

Load impedance both outputs in use: > 32 Ohms

Max output power (into 16 Ohms load):                 0.4W

Max output voltage swing: +/-8V peak

Output impedance: 10 Ohms

Protection: DC, overload



DIGITAL & STREAMING:

Optical input: PCM: 44.1kHz/16bit up to 192kHz/24bit

Coaxial input: PCM: 44.1kHz/16bit up to 192kHz/24bit

Bluetooth support: BT5.0, A2DP, SBC, AAC, aptX-HD



CONNECTIVITY:

Digital inputs: 2 coaxial, 3 optical

Analog inputs: 2 RCA

Analog preamplifier output: 1 RCA

Service port: 1 USB

12V trigger: 1 input, 1 output

Phono MM: 1 RCA

Headphone outputs: 3.5mm jack + 6.35mm jack

Speaker outputs:  1 pair binding posts



WEIGHT & DIMENSIONS:

Weight:  8 kg – 17.6 lbs

Width:   470 mm – 18.5 inches

Depth:    262 mm – 10.3 inches

Height:   90 mm – 3.5 inches



VOLTAGE & POWER CONSUMPTION:

Mains input voltage: 100-240VAC, 50/60Hz, 3A

Idle (no load or signal): 30 W

Standby: < 0.5 W

OFF (main switch OFF): 0 W



*Specifications are subject to change without further notice
