The new ECI 6 MKII is a powerful integrated amplifier equipped with 4 analogue inputs. The ECI 6 MKII offers 2 x 125 Watts and is based on the successful ECI 5 MK II. To enhance it, we have equipped the ECI 6 MKII with an even better power supply and a more sophisticated preamplifier module.
As a result we can offer you an extremely substantial and dynamic amplifier, capable of controlling a wide range of speakers on the market.
Technical specifications
Preamplifier section
Input impedance ( Balanced input )
47Kohm
Maximum input level
10 Volt RMS
Noise floor ( 1Vrms, 20 - 20 kHz, balanced)
-135 dB
THD + N (1Vrms, 20 - 20 kHz, balanced)
<0.004%
Gain (Balanced)
0 dB
Amplifier section
Output Impedance
< 0,02 Ohm
Frequency response
1 – 150 kHz
Channel separation
> 120 dB
THD ( 20 - 20 kHz)
< 0.004%
Maximum peak current
>100A
Damping factor 8 ohm load
>350
I Input sensitivity 120W output
1.3Vrms
Input sensitivity HT 120W output
1Vrms
Gain HT Input
x36 (31 dB)
Rated output power
8 ohms
2 x 125 W
4 ohms
2 x 200 W
2 ohms
2 x 370 W
Power consumption
110 W
Standby
1W
(no load or signal)
Dimensions
Width
470 mm / 18.3 inches
Depth ( with a speaker terminals)
430 mm / 16,9 inches
Height
128 mm / 5 inches
Weight
20,5 Kg / 45 lbs.
