dB Technologies

LVX-P8 WHITE

Passive 2- Way, 8/1", white
CHF 295.00 CHF 295.00 (Tax included)

Wird für Sie bestellt
Add to cart
Allgemeine Geschäftsbedingungen
Versand: 2-3 Arbeitstage

LVX P cabinets are equipped with premium components and are designed to render speech, live or background music in medium to large venues delivering a clear, detailed audio performance.

Full range LVX P8 provides a 90°x70° dispersion pattern and is equipped with a rotatable horn to guarantee the same HF coverage even in case of horizontal install.

The solid plywood enclosures features a clean, install-friendly design featuring 12 M8-thread rigging points to ease installation with dedicated horizontal (WB-LP10H or vertical brackets (VB-LP810V). The cabinet features an integrated handle on back side and a 36 mm pole mount plate. All enclosures and accessories of LVX P series are available in black or white version.

Technical Data
Speaker Type 2-Way Passive Speaker
Acoustical data
Peak Power 400 W
Impedance 8 Ohms
Frequency Response [- 10 dB] 74 - 18.000 Hz
Max SPL 122 dB
HF 1 “, 1" v.c.
Directivity 90x70°
Horn Rotatable
LF 8 “, 1.5" v.c.
Input
Signal Input 1x Speakon (Pin 1+=+) (Pin 1-=-)
Signal Output 1x Speakon (Pin 1+=+) (Pin 1-=-)
Mechanics
Housing Plywood
Pole Mount 36 mm
Angle Up Monitor use 40°
Rigging Points 12 x M8
Handles 1 on back side
Width 255 mm (10.03 in)
Height 426 mm (16.77 in)
Depth 258 mm (10.15 in)
Weight 8.1 kg (17.8 lbs)
