Technical Data
| Speaker Type | 2-Way Active Speaker |
Acoustical data
| Frequency Response [-10dB] | 70 - 20.000 Hz |
| Max SPL | 116 dB |
| HF | 1 " |
| Type HF | Dome Tweeter, coaxial |
| Directivity | 85 x 75 ° |
| LF | 2x 5 “ |
Amplifier
| Amp Technology | digipro® |
| Amp Class | Class D |
| Power PRG | 160 W |
| Cooling | Convection |
Processor
| Controller | DSP 24bit/48kHz |
| System Presets | 8 |
| Limiter | Dual Active Peak, RMS, Thermal |
Input
| Signal Input | 1x XLR Line In/Mic1x 6.3mm phone jack1x RCA cinch AUX with volume ctrl |
| Microphone Input | YES |
| Signal Output | 1x 6.3mm phone jack |
| Power Socket | VDE |
| Voltage Range | 110-120 - 220-240 V |
Mechanics
| Housing | Polyporpylen PP |
| Angles Up | Monitor use 60° |
| Rigging Points | 2x M5 on side2x M5 on bottom for accessories |
| Accessory | WB03, SN120 |
| Width | 200 mm (7.87 in) |
| Height | 335 mm (13.19 in) |
| Depth | 220 mm (8.66 in) |
| Weight | 5.2 kg (11.46 lbs) |
